JRC JMA-5212-4/6 - Marking [MARK]

3.5 GENERAL OPERATIONS
360
3
y
y y
3.5.16 Marking [MARK]
A maximum of 20 marks can be indicated at arbitrary positions on the radar display.
A mark created on the radar display holds the latitude and longitude.
[I] Creating Marks
Procedure 1 Press [MARK] key.
[غ] will appear in the CURSOR field at the upper right of the radar display.
2 Put the cross cursor mark + on the position where a mark is to be
created, and press [ENT] key.
The cross cursor mark + will be changed into the [غ] mark and fixed on the radar
display. To enter more [غ] marks, repeat step 2.
Up to 20 marks can be entered.
Note:
If more than 20 marks are created, the oldest mark is cleared and the newly created mark is
displayed.
[II] Clearing Marks
Procedure 1 Press [MARK] key.
The [غ] mark will appear in the CURSOR field at the upper right of the radar display.
2 Put the cross cursor mark + on the mark to be cleared.
The [غ] mark will disappear. To clear another [غ] mark, repeat step 2.
To clear all [غ] marks, press [MARK] key and then hold down [CLR] key.
* Software button Ԙ located at the top right corner of the radar display described in Section 2.3.3 changes
the cursor mode. When "غ" appears, the cross cursor is available to create "غ" mark.
