2.3 FUNCTIONS OF SOFTWARE BUTTONS
This radar provides the software buttons on the display which can be used to set several important functions
directly and swiftly from the display without opening the corresponding menu.
The names of buttons are described on the following pages.
By positioning the arrow cursor to a button in the figure above and then clicking the left button of the trackball,
the setting can be changed as shown below.
Note : Latitude and longitude in Area 5 is the value of CCRP.
Area 1
(Top-left corner of
the radar dis
p
la
y)
Area 3
(Top-right corner of
the radar dis
p
la
y)
Area 2
(Bottom-left corner of
the radar dis
p
la
y)
Area 4
(Bottom-right corner of
the radar dis
p
la
y)
Area 5
(Own ship’s information)
Area 6
(Other ship’s information)
Area 7
(Panel display)
Area 8
(Operation/message)
