5.1.7 Setting Vectors (Vector Time)
Vector time can be set in minutes in the range 1 to 60 min.
A true vector mode or relative vector mode can be selected.
Setting vector time on the display
Procedure 1 Move the cursor to the target vector time setting (Software button
ԙ
located at the other ship's information area in Section 2.3.6), and press
the [ENT] key.
The Vector Time value input screen will appear.
2 Use number keys, input a vector length, and press the [ENT] key.
The inputted vector length is confirmed.

Setting vector time using the multi-dial [MULTI]
Procedure 1 Press the [MULTI] dial several times to activate the Vector mode.
Vector will be displayed in the multi-dial mode (ԥ located at the bottom left corner of
the radar display described in Section 2.3.2).
2 Turn the [MULTI] dial to set the vector time.
Setting vector mode [VECT R / T]
Procedure 1 Press the [VECT R / T] key.
The current vector mode T (true vector) or R (relative vector) will be displayed in
the target vector display true / relative switching (software button Ԙ located at the other
ship's information area in Section 2.3.6).
The vector mode is switched between T (true vector) and R (relative vector) each
time the button is pressed.
