8.3 PERFORMANCE CHECK
88
8
yyyy
yyyy
8.3.1.1 Self-diagnosis function
Check of Memory, Scanner Unit, and Communications Lines
Memory Test
1) Memory check
Sensor Test
2) Antenna check
Line Test
3) Communication line check
Procedure 1 Press [1] key while the Test Menu is
open.
The SELF TEST Menu will appear.
2 Select the item you want to check,
pressing numeric keys [1] to [3] .
The SELF CHECK Menu will appear.
Exit 1 Press [RADAR MENU] key.
The Self Test Menu will be closed.
[I] Memory Test
Checks for the performance of built-in memory.
SDRAM
SDRAM check
SRAM
SRAM check
FLASH ROM
Flash ROM check
GRAPHIC
Graphic check
Procedure 1 Press [1] key while the Self Test menu
is open.
The Memory Test Menu will appear.
2 Select the item you want to check,
pressing numeric keys [1] to [4].
When no abnormality is found, OK is displayed.
When an abnormality is found, NG is displayed.
Exit 1 Press [RADAR MENU] key.
The menu will be closed.
To Next Page
