747
4 Press [2] key.
The numeric keypad to be used in MBS Area Menu will appear.
5 Input “20” as an MBS Area setting value.
The value can also be entered with the multi-dial.
Press [ENT] key after inputting the value.
6 Input [1] key.
The numeric keypad to be used in MBS Area Menu will appear.
7 Input an MBS area setting value such that the main bang image remains
lightly on the display.
The value can also be entered with the multi-dial.
Press [ENT] key after inputting the value.
8 Press [2] key.
The numeric keypad to be used in MBS Area Menu will appear.
9 Input an MBS area setting value such that the suppression area and the
main bang image completely overlap with each other.
The value can also be entered with the multi-dial.
Press [ENT] key after inputting the value.
Exit 1 Press [RADAR MENU] key.
The Main Menu will reappear.
