Table 8-2 System alarm warning list 1: Antenna
Message Description
TXRX(SSW Off) Antenna Safety switch is off
TXRX(AZI) Antenna Rotation signal error
TXRX(HL) Antenna Reference rotation signal error
TXRX(MHV) Antenna Abnormal modulated high voltage
TXRX(Time Out) Antenna No communication
TXRX(Data) Antenna
Abnormality in communication data, abnormality in checksum, and data disagreement
TXRX(Heater) Antenna Abnormal MAG heater voltage
TXRX(Reverse) Antenna Abnormality in reverse rotation
TXRX(Video) Antenna Abnormality in the video
TXRX(Trigger) Antenna Abnormality in the trigger
TXRX(Fan 1) Antenna Abnormality in Fan 1
TXRX(Fan 2) Antenna Abnormality in Fan 2
TXRX(Motor) Antenna Abnormal motor current
Table 8-3 System alarm warning list 2: Display
Message Description
Keyboard(Time Out) Keyboard No communication
Keyboard(Data) Keyboard
Abnormality in communication data, abnormality in checksum, and data disagreement
Keyboard2(Time Out) Keyboard 2 No communication
Keyboard2(Data) Keyboard 2
Abnormality in communication data, abnormality in checksum, and data disagreement
PROC(Interrupt) Signal processor Abnormal interrupt
PROC(AZI) Signal processor Abnormal rotation signal
PROC(HL) Signal processor Abnormal reference rotation signal
PROC(Reverse) Signal processor Abnormality in reverse rotation
PROC(Video) Signal processor Abnormality in the video
PROC(Trigger) Signal processor Abnormality in the trigger
ASIC(ASIC1 to RADAR)
Abnormal interrupt from ASIC1 to RADAR DSP
AIS PROC(Time Out) AIS I/F No communication
AIS PROC(Data) AIS I/F Abnormality in communication data and abnormality in checksum
Indicator(Fan) Display Abnormality in the fan
