4-5
: The EBL starting point is defined as the own ship's position.
C : The EBL starting point is moved and fixed on the radar display.
D : The EBL starting point is moved and fixed at the latitude and longitude.
(The navigator needs to be connected.)
To move the starting point of EBL
Procedures 1 Make EBL1 or EBL2 operable.
2 Press the [EBL] dial to set C or D for the EBL1 / EBL2 starting
point mode located at the upper right of the radar display.
The selected EBL starting point mode is switched as shown below each time the dial is
pressed.
⇒ C ⇒ D ⇒
3 Put the cursor on the EBL starting point is to be moved, and left-click.
The selected EBL starting point will be determined.
To return the EBL starting point to own ship's position
Procedures 1 Make EBL1 or EBL2 operable.
2 Press the [EBL] dial to set (blank) for the EBL1 / EBL2 starting
point mode located at the upper right of the display.
The selected EBL starting point will be set as the own ship's position.
