[II] Target Tracking Simulator
Pseudo targets are generated in certain known positions to check whether the target tracking units are operating
normally. Since the pseudo targets move depending on known parameters, the values for these pseudo targets
can be compared with the known value if the pseudo targets are acquired and tracked, and displayed. Thus, it
can be checked if the system is operating normally.
Procedures 1 Press the [TX/STBY] key to stop the transmitting.
The equipment will enter the transmission standby state.
2 Open the TT Test Menu by performing the following menu operation.
TT
→ TT Test Menu
3 Left-click the item button of TT Simulator .
The setting items for TT Simulator will be displayed.
4 Select the scenario to be set.
5 Press the [TX/STBY] key to transmit.
The simulator will be activated and generate pseudo targets. The characters "X" at the
bottom of the radar display blinks indicating that the simulation mode is active.
Target tracking simulator / scenario
Target start point Target end point
Scenario
Distance Bearing Distance Bearing
Pseudo-target speed
1
3.2nm
20°
1nm
90°
20kn
2
6nm
0°
0nm
0°
10kn
3
6nm
every 18°
1nm
every 18°
10kn
4
6nm
45°
1nm
45°
105kn
5
6nm
45°
6nm
150°
20kn
6
6nm
45°
6nm
150°
20kn
Note:
When the simulator is operating, set 0° as the heading bearing, and 0 kn as the speed of own ship.
When the range between own ship and the pseudo target is 0, the target will disappear.
