Technical Specications
Operang Temperature, Humidity, and
Atmospheric Pressure
10 %
90 %
50 kPa
106 kPa
Transportaon and Storage Condions
10 %
100 %
50 kPa
106 kPa
Internal Power Source
Non-User serviceable,
Lithium Polymer baery
Recharge me Four(4) - six(6) connuous hours of charging following inial charge
Baery conservaon Instruments transion to “o power” state when not in use
Specied Power Supply,
(Baery Charger)
J
TECH Medical PN: PW006 [Protek Power PMP15M-10-B6] or
JTECH Medical PN: PW008 [Globtek, Inc. WR9QA3000CCP-N-MED]
Type of Operaon Connuous
Type of Protecon against electric shock Internally powered equipment
Degree of protecon against electric shock
Type B equipment
Protecon against harmful ingress of water IPX0 - ordinary equipment
Degree of Safety of Applicaon in the presence
of ammable mixtures
This device is not suitable for use in the presence of ammable anesthec mixture
with air, or with oxygen or nitrous oxide
This device contains:
FCC ID: OUR-XBEE
Model XBee-Radio, Canada IC: 4214A-XBEE
Japan ID: 005NYCA0378
RF operang distance 3 meters (9.8 feet) from console, indoor environment
RF frequency 2.4GHz wireless frequency
Symbols
I P X 0
Medical Device Class
Class I measuring medical device per Annex IX of Council Direcve 93/42/EEC
Class I medical device per CFR Title 21 Part 888 Supbart B
Class II medical device per Rule 10 of the Canadian Medical Devices Regulaons
Dimensions
Weight
Maximum Force Input
Operang Temperature, Humidity, and
Atmospheric Pressure
10 %
90 %
50 kPa
106 kPa
Transportaon and Storage Condions
10 %
100 %
50 kPa
106 kPa
Type of Operaon Connuous
Input Voltage
100-240 VAC
Input Frequency 50-60 Hz
Input Current 0.5 A (rms) for 115 VAC
0.3 A (rms) for 240 VAC
Enclosure Leakage Current 100 uA max. @ 264 VAC, 63 Hz
Maximum Output Voltage/Current 5 V / 3 A
Maximum Output Power 15 W
Type of Protecon against electric shock
Class II
Manufacture, Model JTECH Medical PN: PW006 [Protek Power PMP15M-10-B6]
Protecon against harmful ingress of water IPX0 - ordinary equipment
Degree of Safety of Applicaon in the presence
of ammable mixtures
This device is not suitable for use in the presence of ammable anesthec mixture
with air, or with oxygen or nitrous oxide
Symbols
I P X 0
Dimensions 7.8 cm x 5.2 cm x 3.5 cm (3.1 in x 2.0 in x 1.4 in)
Weight 0.21 kg (0.38 lb)
Specified Power Supply (Battery Charger) (PW006*)
Used with the Daisy Chain for charging your Echo devices.
*Power supply connecon may vary according to the country shipped to
