JUKI SC-910N Engineer's Manual

– 51 –
116 Selection of When the IP-110 is connected, switch selection is performed U 0 to 6 65
corner teaching to start in-corner sewing in the case of corner pattern sewing.
start switch 0: No function
1: Left needle selector switch
2: Right needle selector switch
3: Teaching switch
4: Optional switch
5: Knee switch, presser lifter switch
6: No function (Don’t care.)
* When 1: left needle selector switch, 2: right needle selector
switch, or
3: teaching switch is selected for the in-corner selector
switch, set
No.111 unilateral needle selection function (corner
pattern) at 0 (function disabled), without fail.
* Setting is possible only if LH-4168 or LH-4188 is selected for
the machine head.
117 Selection of When the knee switch is connected, selection is performed U 0/1 66
presser lifter to stop/start the automatic presser lifter function by means
switch function of the knee switch.
0: OFF The automatic presser lifter is stopped with the
knee switch.
1: ON The automatic presser lifter is used with the
knee switch.
* Setting is possible only if LH-4168 or LH-4188 is selected for
the machine head.
* When using this function, it is necessary to set up the
presser lifter switch half-needle compensation function
(No. 106) to Position 0 (function disabled).
118 Grease up error In the case of grease-up error (E220, E221), this error is U 0/1 66
reset cleared by setting the setup description at 1.
0: Normal condition
1: Grease-up error reset when the power is turned on for
the next time (After grease-up error has been reset, this
function is also canceled.)
* Prior to resetting the grease-up error, grease-up treatment
is always needed.
* Setting is possible only for the machine head (part of the
LH-4100 or LH-3500 Series) where grease-up treatments
are needed.
120 Main shaft Main shaft reference angle is compensated. U –35 to 35° 66
reference angle
compensation
121 Correction of Angle to detect UP position stating is compensated. U –15 to 15° 66
upper position
stop angle
122 Correction of Angle to detect DOWN position stating is compensated. U –15 to 15° 66
lower position
stop angle
125 Designation of When reverse stitching is started with the reverse stitching S 200 to 66
reverse stitching switch or the like, the number of revolutions at the machine maximum
speed head is reduced to the specified speed. (rpm)
(This function becomes valid when the DDL-9000A is selected.)
6
1
1
5
7
1
1
0
8
1
1
0
0
2
1
1
2
-
1
2
1
2
2
2
1
0
No. Item Description Start level Setting range
Indication of
function setting
Ref.
page
o
o
∗
∗ Do not change the set values with asterisk (*) mark as they are functions for maintenance. If the standard set value set at the time
of delivery is changed, it is in danger of causing the machine to be broken or the performance to be deteriorated.
(Descriptions of setting in this list are the standard values at the time of delivery of DDL-9000A.)
However, contents of function setting are subject to change for improvement of function and performance without notice.
o Any version with the o mark is indicated when the LH-4168, LH-4168D, or LH-4188 machine head is selected.
o
5
2
1
0
0
3
3
