JUKI SC-910N Engineer's Manual

– 50 –
108 In-corner presser When the IP-110 is connected and a corner pattern is selected, U 0/1 63
ifter function this function is used to perform automatic presser rising after
the completion of in-corner sewing.
0: OFF Automatic presser rising disabled after the completion
of in-corner sewing
1: ON Automatic presser rising enabled after the completion
of in-corner sewing
* Setting is possible only if LH-4168 or LH-4188 is selected
for the machine head.
* This function is available only if the automatic presser
lifter unit (AK) is connected.
109 Re-sewing When the IP-110 is connected, this function is used to stop/ U 0/1 64
function start sewing again (sewing retried in the middle of operation).
0: OFF Re-sewing function disabled
1: ON Re-sewing function enabled
* Setting is possible only if LH-4168 or LH-4188 is selected
for the machine head.
110 Unilateral needle When a reverse or overlapped stitching pattern is selected, U 0/1 64
selection function this function is used to stop/start the unilateral needle selection.
(Free stitching/ When 0 (disable) is selected, unilateral needle selection is
overlapped disabled for the reverse or overlapped stitching pattern.
stitching) 0: OFF Unilateral needle selection function (during free
stitching) disabled
1: ON Unilateral needle selection function (during free
stitching) enabled
* Setting is possible only if LH-4168 or LH-4188 is selected
for the machine head.
111 Unilateral needle When the IP-110 is connected and a corner pattern is selected, U 0/1 64
selection function this function is used to stop/start the unilateral needle selection.
(Corner pattern) When 0 (disable) is selected, arbitrary unilateral needle selection
is disabled for the corner pattern.
0: OFF Unilateral needle selection function (during corner
pattern) disabled
1: ON Unilateral needle selection function (during corner
pattern) enabled
* Setting is possible only if LH-4168 or LH-4188 is selected
for the machine head.
112 Selection of Selection of operation available when the teaching switch is U 0 to 2 64
teaching pressed.
operation 0: Normal (Teaching operation is performed under the con
ditions of teaching + unilateral needle selection.)
1: Teaching operation only by unilateral needle selection
(It is unnecessary to press the teaching switch in order to
start up the teaching operation.)
2: Teaching operation disabled in the unilateral needle state
(Press the teaching switch after the bilateral needle state
has been assumed.)
* Setting is possible only if LH-4168 or LH-4188 is selected
for the machine head.
113 Number of Selection of the number of reproduced stitches when corner U 0/1 65
stitches for teaching (measuring the number of stitches for unilateral needle
teaching replay sewing) is carried out.
0: The number of replay stitches coincides with that of
measured stitches.
1: The number of replay stitches is less by 1 than that of
measured stitches .
* Setting is possible only if LH-4168 or LH-4188 is selected
for themachine head.
114Left bobbin When the IP-110 is connected, this function is used to U 0/1 65
thread counter stop/start the left bobbin thread counter.
function 0: OFF Left bobbin thread counter function disabled
1: ON Left bobbin thread counter function enabled
*S etting is possible only if LH-4168 or LH-4188 is selected
for the machine head.
115 Right bobbin When the IP-110 is connected, this function is used to U 0/1 65
thread counter stop/start the right bobbin thread counter.
function 0: OFF Right bobbin thread counter function disabled
1: ON Right bobbin thread counter function enabled
* Setting is possible only if LH-4168 or LH-4188 is selected
for the machine head.
5
1
1
1
No. Item Description Start level Setting range
Indication of
function setting
Ref.
page
8
0
1
1
9
0
1
1
0
1
1
1
1
1
1
1
2
1
1
0
3
1
1
0
4
1
1
1
o
o
o
o
o
o
o
o
o Any version with the o mark is indicated when the LH-4168, LH-4168D, or LH-4188 machine head is selected.
