– 49 –
93 Function added Operation of needle up/down compensating switch is U 0/1 61
to needle up/ changed after turning ON the power or thread trimming.
down compen- 0 : Normal (needle up/down compensating stitching only)
sating switch 1 : One stitch compensating stitching is performed only when
aforementioned changeover is made. (Upper stop /
upper stop)
94
Continuous In IP-110 program functions, a function that does not stop U 0/1 61
stitching + one- the sewing machine by combining continuous stitching with
shot stitching one-shot stitching when the step is changed.
non-stop function 0 : Normal (The sewing machine stops when a step
is completed.)
1 : The sewing machine does not stop when a step is
completed and proceeds to next step.
95 Function of The machine head to be used is selected. U 42
machine head * When the machine head is changed, each setting item
selection is modified into initial values for the machine head.
96 Max. number of Max number of rotation of the sewing machine head can be set. U 50 to MAX 61
rotation setting According to the type of the head to be connected, the
upper limits of the setting values may change.
100 Number of Not used. (Do not change the set value.) U 0 to 9 54
stitches of
tension release
motion at the
sewing start
101 Sewing This function selects the input destination of the sewing counter. U 0/1 62
counter input 0 : Every time thread trimming is performed, the counter
function automatically counts up.
1 : The counter counts up by inputting of the external sewing
counter SW
102 Function of test The I/O status can be examined at the panel display. S 0 to10 63
display mode This function is valid only at the time of maintenance.
Never use it in regular operation. (Normal display cannot
be presented.)
104 Locking PWM Not used. (Do not change the set value.) S 30 to 200
at the start of
the main shaft
105 Touch back When the IP-110 is connected and a corner pattern is selected, U 0/1 63
switch half-needle
this function provides the capability of stitch compensation
compensation during in-cornersewing with the aid of a touch back switch.
function 0: OFF Compensation sewing disabled with the touch
back switch
1: ON Compensation sewing enabled with the touch
back switch
* Setting is possible only if LH-4168 or LH-4188 is selected
for the machine head.
106 Presser lifter When the IP-110 is connected and a corner pattern is selected, U 0/1 63
switch half-needle
this function provides the capability of stitch compensation
compensation during in-corner sewing the the aid of a presser lifter switch.
function 0: OFFCompensation sewing disabled with the presser
lifter switch
1: ON Compensation sewing enabled with the presser
lifter switch
* Setting is possible only if LH-4168 or LH-4188 is selected
for the machine head.
* When using this function, it is necessary to set up the
presser lifter function selection (No.117) at 0 (function
disabled).
107 In-corner sewing When the IP-110 is connected and a corner pattern is selected, U 0/1 63
one-shot function this function is used to perform automatic one-shot sewing
for in-corner sewing.
0: OFF Automatic one-shot sewing disabled during in-
corner sewing
1: ON Automatic one-shot sewing enabled during in-
corner sewing
* Setting is possible only if LH-4168 or LH-4188 is selected
for the machine head.
No. Item Description Start level Setting range
Indication of
function setting
Ref.
page
o
o
∗
∗ Do not change the set values with asterisk (*) mark as they are functions for maintenance. If the standard set value set at the time
of delivery is changed, it is in danger of causing the machine to be broken or the performance to be deteriorated.
(Descriptions of setting in this list are the standard values at the time of delivery of DDL-9000A.)
However, contents of function setting are subject to change for improvement of function and performance without notice.
o Any version with the o mark is indicated when the LH-4168, LH-4168D, or LH-4188 machine head is selected.
o
