JUKI SC-910N Engineer's Manual

– 48 –
66 On-timing of Starting (compensation) timing of solenoid for condensation U -36 to 0 54
solenoid for stitch : -2 (10°)
condensation Compensation value of starting the solenoid when
stitch (when condensation stitch is performed by 2 stitches.
condensation
stitch is performed
by 2 stitches.)
67 Presser foot Duty of presser foot lifting solenoid output (%) U 5 to 40 60
lifting solenoid (1%)
output duty
setting
68 High-speed The unilateral needle changeover speed is set at high speed. U 0/1
function for 0 : Standard
unilateral needle 1 : High speed
changeover
70 Function of Presser foot is slowly lowered. U 0/1 60
soft-down of 0 : Presser foot is rapidly lowered.
presser foot 1 : Pres
71 Function of Speed limitation is performed at the time of re-acceleration U 0 to 5 60
limitation of re- on the way of reducing speed of the sewing machine.
acceleration from It is effective when operating inching sewing.
reduction of speed
72 Function of Speed limitation is performed at the time of start-up of the sewing U 0 to 5 60
limitation of machine (excluding the start of sewing).
acceleration at It is effective when operating inching sewing.
the start of rotation
73 Retry function This function is used when needle cannot pierce materials . U 0/1 61
0 : Normal
1 : Retry function is provided.
75 Rotating Normal rotating direction of motor U 0/1 62
direction of 0 : Clockwise
motor 1 : Counterclockwise
76 Function to Starting curve of the sewing machine is selected. U 0/1 61
select the start- 0 : Normal curve
up speed of the 1 : More sharp curve
sewing machine
84 Initial motion Suction motion time of presser foot lifting solenoid. U 40 to 300 61
suction time of (ms)
presser foot
lifting solenoid
87 Function of Pedal curve is selected. (Improving pedal inching operation) U 0/1/2 61
pedal curve
selection
89 Feed and return This function is used to define whether the feed and return U 0/1 54
solenoid solenoid (LZ) is actuated or not.
0 : Operation disabled
1 : Function enabled
90 Function of Automatic UP stop function is set immediately after turning U 0/1 61
upper position ON the power.
stop shortly 0 : OFF
after Power ON 1 : ON
91 Function of Function of compensating stitching when turning handwheel U 0/1 62
prohibiting by hand at the time of completion of constant-dimension
compensation stitching
operation after 0 : Function of compensating stitching is effective.
turning 1 : Function of compensating stitching is prohibited.
handwheel by
hand
92 Function of Function to reduce speed at the time of completion of U 0/1 60
reducing speed reverse feed stitching at the start of sewing.
stitching at the 0 : Speed is not reduced.
start of sewing 1 : Speed is reduced.
5
7
0
6
7
0
4
8
0
0
1
7
8
0
9
8
0
0
9
1
1
9
1
2
9
0
No. Item Description Start level Setting range
Indication of
function setting
Ref.
page
3
7
1
1
7
0
2
7
0
6
6
5
-
1
7
6
0
2
8
6
0
0
7
0
Pedal stroke
Number of rotations
2
0
1
∗ Do not change the set values with asterisk (*) mark as they are functions for maintenance. If the standard set value set at the time
of delivery is changed, it is in danger of causing the machine to be broken or the performance to be deteriorated.
(Descriptions of setting in this list are the standard values at the time of delivery of DDL-9000A.)
However, contents of function setting are subject to change for improvement of function and performance without notice.
∗
∗
o
o Any version with the o mark is indicated when the LH-4168, LH-4168D, or LH-4188 machine head is selected.
