JUKI SC-910N Engineer's Manual

– 55 –
@@
@@
@ Function of changeover of compensating switch on the operation panel function (Function setting No. 22)
Function of compensation switch on the operation panel of CP-170 or IP-110 can be changed over to needle up
/ down compensating stitching or one stitch compensating stitching.
0 : Needle up / down compensating stitching
1 : One stitch compensating stitching
##
##
# Thread trimming motion condition (Function setting No. 25)
This function is used to make the thread trimming motion ineffective when the back part of the pedal is de-
pressed after the displacement from the UP or DOWN position while the hand wheel is being turned by hand.
0 : Thread trimming motion is effective.
1 : Thread trimming motion is prohibited.
$$
$$
$ Function of setting the holding force after stop (Function setting No. 26)
Function to prevent the increased amount of reverse rotation after stop when the machine has been used for a
long time and the machine head torque has become light. When the set value is increased, the prevention effect
becomes large. However, when the set value is excessively increased, on the contrary, there is a danger that the
machine normally rotates. Adjust the function while checking the motion of the needle bar.
Setting range : 0 to 9
%%
%%
% Function of setting the reaction force at the time of retry (Function setting No. 27)
This function changes the magnitude of the reversing force before moving to the retry motion.
Setting range : 1 to 100
1 : Less reversing force to 100 : More reversing force
^^
^^
^ Setting of the suction time of the back-tack solenoid (Function setting No. 29)
This function can change the suction time of the back-tack solenoid.
It is effective to decrease the value when the heat is high.
(Caution) When the value is excessively decreased, failure of motion or defective pitch will follow.
Be careful when changing the value.
Setting range : 50 to 300 ms <10 / ms>
&&
&&
& Function of reverse feed stitching on the way (Function setting Nos. 30 to 33)
Functions of the limit of number of stitches and thread trimming command can be added to the touch back switch
on the sewing machine head.
Function setting No. 30 Function of reverse feed stitching on the way is selected.
0 : off Normal back-tack function
1 : on Function of reverse feed stitching on the way
Function setting No. 31 Number of stitches performing reverse feed stitching is set.
Setting range
0 to 19 stitches
Function setting No. 32 Effective condition of reverse feed stitching on the way
0 : off Inoperative when the sewing machine stops.
(Reverse feed stitching on the way functions only when the sewing machine
is running.)
1 : on Operative when the sewing machine stops.
(Reverse feed stitching on the way functions both when the sewing machine
is running and stops.)
(Caution) Either condition is operative when the sewing machine is running.
Function setting No. 33 Thread trimming is performed when reverse feed stitching on the way is com-
pleted.
0 : off Without thread trimming
1 : on Thread trimming is executed.
2
2
0
5
2
1
6
2
0
7
2
0
5
9
2
2
0
5
0
3
0
1
3
4
2
3
0
3
3
0
