– 56 –
Actions under each setting state
Function setting
No. 30 No. 32 No. 33
100 or 1 0 or 1 It works as normal touch-back switch.
When operating touch-back switch at the time of depressing front part of the
2 100pedal, reverse feed stitching as many as the number of stitches specified by
the function setting No. 31 can be performed.
When operating touch-back switch at the time of either stop of the sewing machine
3 110or depressing front part of the pedal, reverse feed stitching as many as the
number of stitches specified by the function setting No. 31 can be performed.
When operating touch-back switch at the time of depressing front part of the pedal,
4 101automatic thread trimming is performed after reverse feed stitching as many as
the number of stitches specified by the function setting No. 31 has been performed.
When operating touch-back switch at the time of either stop of the sewing machine
or depressing front part of the pedal, automatic thread trimming is performed
after reverse feed stitching as many as the number of stitches specified by the
function setting No. 31 has been performed.
1 Used as the normal reverse feed stitching touch-back switch.
2 Used for reinforcing seam (press sewing) of the pleats. (It works only when the sewing machine is running.)
3 Used for reinforcing seam (press sewing) of the pleats.
(It works either when the sewing machine stops or when the sewing machine is running.)
4 Used as starting switch for reverse feed stitching at the sewing end.
(Used as the substitute for thread trimming by depressing back part of the pedal. It works only when the sewing machine
is running. It is especially effective when the sewing machine is used as the standing-work machine.)
5 Used as starting switch for reverse feed stitching at the sewing end.
(Used as the substitute for thread trimming by depressing back part of the pedal. It works either when the
sewing machine stops or when the sewing machine is running. It is especially effective when the sewing
machine is used as the standing-work machine.)
**
**
*
Number of rotation of one-shot stitching (Function setting No. 38)
This function can set, by the pedal operation of one time, the sewing speed of one-shot stitching when the sewing machine
continues stitching until completing the number of stitches specified or detecting the material end.
Setting range
200 to MAX. rpm. <50 / rpm>
(Caution)1. Setting of the one-shot stitching is made by the control panel of the CP-170 or higher class model.
2. The max. number of rotation of one-shot stitching is limited by the model of the sewing
machine head.
5 111
