– 28 –
*
89
Tension release
function
This function is effective in combination with the machine head with
bird's nest prevention function (Optional unit A is necessary).
0 : Motion is prohibited.
1 : Motion of thread draw-out/return solenoid is prohibited.
0/1
8 9 0
32
90
Initial motion up
stop function
Automatic UP stop function is set immediately after turning ON the
power.
0 : off
1 : on
0/1
9 0 1
38
*
91
Function of prohibiting
compensation
operation after turning
handwheel by hand
It is effective in combination with the machine head provided
with tension release function.
0 : Tension release function is ineffective.
1 : Tension release function is effective.
0
/
1
9 1 1
92
Function of
reducing speed
of reverse feed
stitching at the
start of sewing
Function to reduce speed at the time of completion of reverse
feed stitching at the start of sewing.
0 : Speed is not reduced.
1 : Speed is reduced.
0
/
1
9 2 0
38
93
Function added to
needle up/down
compensating
switch
Operation of needle up/down compensating switch is changed after
turning ON the power or thread trimming.
0 : Normal (needle up/down compensating stitching only)
1 : One stitch compensating stitching is performed only when aforemen-
tioned changeover is made. (Upper stop
/
upper stop)
0
/
1
9 3 0
38
94
Continuous
stitching + one-
shot stitching non-
stop function
In IP-110 program functions, a function that does not stop the sewing
machine by combining continuous stitching with one-shot stitching
when the step is changed.
0 : Normal (The sewing machine stops when a step is completed.)
1 : The sewing machine does not stop when a step is completed
and proceeds to next step.
0
/
1
9 4 0
39
95 Head selection
function
Machine head to be used is selected.
* When the machine head is changed, each setting item is
changed to the initial value of the machine head.
9 5 d L A
U
13
96
Max. number of
rotation setting
Max. number of rotation of the sewing machine head can be set.
50 to MAX
(rpm)
9 6 4 0 0 0
39
*
100 Number of
stitches of
tension release
motion at the
sewing start
This function is effective in combination with the machine head with
bird's nest prevention function. (Optional unit A is necessary).
This function sets the number of stitches to make the tension release
solenoid actuate at the sewing start.
0 : Tension release motion is prohibited.
1 to 2 stitches : Number of stitches of tension release motion
0 to 9
1
0 0 0
32
101 Sewing counter
input function
This function selects the input destination of the sewing counter.
0 : Every time thread trimming is performed, the counter automati-
cally counts up.
1 :
The counter counts up by inputting of the external sewing counter SW
0
/
1
1
0 1 0
39
105 Touch back
switch needle
up/down
compensating
stitching
function
When connecting IP-110 and selecting the corner pattern, this function performs
compensating stitching during sewing in-corner with the touch back switch.
0 : Touch back switch compensating stitching is invalid.
1 : Touch back switch compensating stitching is valid.
* It is possible to set only when LH-4168 or LH-4188 is selected for
the machine head.
0
/
1
1
0 5 0
106 Presser lifting
switch one stitch
compensating
function
When connecting IP-110 and selecting the corner pattern, this func-
tion performs compensating stitching during sewing in-corner with the
presser lifting switch.
0 : Presser lifting switch compensating stitching is invalid.
1 : Presser lifting switch compensating stitching is valid.
* It is possible to set only when LH-4168 or LH-4188 is selected for
the machine head.
* When using this function, set the presser lifting switch function
selection (No. 117) to “0” (function invalid).
0
/
1
1
0 6 1
107 In-corner
sewing one-shot
function
When connecting IP-110 and selecting the corner pattern, this
function performs one-shot automatic sewing of in-corner sewing.
0 : One-shot automatic sewing of in-corner sewing is invalid.
1 : One-shot automatic sewing of in-corner sewing is valid.
* It is possible to set only when LH-4168 or LH-4188 is se-
lected for the machine head.
0
/
1
1
0 7 0
108
In-corner presser
lifting function
When connecting IP-110 and selecting the corner pattern, this
function performs automatic presser lifting after completion of
the in-corner sewing.
0 : Automatic presser lifting after in-corner sewing is invalid.
1 : Automatic presser lifting after in-corner sewing is valid.
* It is possible to set only when LH-4168 or LH-4188 is se-
lected for the machine head.
* This function is valid only when the automatic presser lifting
device (AK) is connected.
0
/
1
1
0 8 1
109
Resewing
function
When connecting IP-110, this function stops/uses resewing
(resewing from a point on the way).
0 : Resewing function is invalid.
1 : Resewing function is valid.
* It is possible to set only when LH-4168 or LH-4188 is se-
lected for the machine head.
0
/
1
1
0 9 1
No
Item Description
Setting range
Indication of function setting
Ref. page
*
Do not change the set values with asterisk (*) mark as they are functions for maintenance. If the standard set value set at the
time of delivery is changed, it is in danger of causing the machine to be broken or the performance to be deteriorated.
If it is necessary to change the set value, please purchase the Engineer’s Manual and follow the instructions.
(Descriptions of setting in this list are the standard values at the time of delivery of DDL-9000A.)
However, contents of function setting are subject to change for improvement of function and performance without notice.
Items with mark are displayed when the machine heads of LH-4168, LH-4168D and LH-4188 are selected.
To Next Page
