JUKI SC-910N User Manual

– 29 –
ENGLISH
No Item Description Setting range Indication of function setting Ref. page
110 Separately
driven needle
changeover
function (free
stitching/
overlapped
stitching)
When selecting reverse stitching pattern/overlapped stitching
pattern, this function stops/uses the separately driven needle
changeover function.
When “0” (invalid) is selected, the separately driven needle
changeover is not possible with reverse stitching pattern/over-
lapped stitching pattern.
0 : Separately driven needle changeover function (during free
stitching) is invalid.
1 : Separately driven needle changeover function (during free
stitching) is valid.
* It is possible to set only when LH-4168 or LH-4188 is se-
lected for the machine head.
0
/
1
1 1 0 1
111 Separately
driven needle
changeover
function (corner
pattern)
When connecting IP-110 and selecting the corner pattern, this
function stops/uses the separately driven needle changeover
function.
When “0” is selected, it is not possible to optionally perform the
separately driven needle changeover with the corner pattern.
0 : Separately driven needle changeover (during corner pat-
tern) is invalid.
1 : Separately driven needle changeover (during corner pat-
tern) is valid.
* It is possible to set only when LH-4168 or LH-4188 is se-
lected for the machine head.
0
/
1
1 1 1 1
112 Teaching motion
selection
Selection of the motion when pressing the teaching switch
0 : Normal : teaching motion with teaching + separately driv-
en needle changeover)
1 : Teaching motion with separately driven needle change-
over only (when starting teaching motion, it is not neces-
sary to press the teaching switch.)
2 : Teaching motion in the state of separately driven needle
is prohibited. (Set the state to two-needle state and press
the teaching switch.)
* It is possible to set only when LH-4168 or LH-4188 is se-
lected for the machine head.
0 to 2
1 1 2 0
113 Number of
stitches of
teaching replay
This function selects the number of stitches of replay when per-
forming corner teaching (measurement of number of stitches of
separately driven needle sewing).
0 : Number of stitches of replay corresponds to that of mea-
surement.
1 : Number of stitches of replay is that which is subtracted
one stitch from number of stitches of measurement.
* It is possible to set only when LH-4168 or LH-4188 is se-
lected for the machine head.
0
/
1
1 1 3 0
114 Left bobbin thread
counter function
When connecting IP-110, this function stops/uses left bobbin
thread counter function.
0 : Left bobbin thread counter is stopped.
1 : Left bobbin thread counter is used.
* It is possible to set only when LH-4168 or LH-4188 is se-
lected for the machine head.
0
/
1
1 1 4 1
115 Right bobbin
thread counter
function
When connecting IP-110, this function stops/uses right bobbin
thread counter function.
0 : Right bobbin thread counter is stopped.
1 : Right bobbin thread counter is used.
* It is possible to set only when LH-4168 or LH-4188 is se-
lected for the machine head.
0
/
1
1 1 5 1
116 Corner teaching
start switch
selection
When connecting IP-110, this function selects the switch to start
in-corner sewing in the corner pattern sewing.
0 : No function
1 : Left needle changeover switch
2 : Right needle changeover switch
3 : Teaching switch
4 : Optional switch
5 : Knee switch and presser lifting switch
6 : No function (Do not set.)
* When selecting 1 : Left needle changeover switch, 2 : Right
needle changeover switch or 3 : Teaching switch for in-cor-
ner changeover switch, be sure to set No. 111 Separately
driven needle changeover function (corner pattern) to “0”
(function invalid).
* It is possible to set only when LH-4168 or LH-4188 is se-
lected for the machine head.
0 to 6
1 1 6 5
*
Do not change the set values with asterisk (*) mark as they are functions for maintenance. If the standard set value set at the
time of delivery is changed, it is in danger of causing the machine to be broken or the performance to be deteriorated.
If it is necessary to change the set value, please purchase the Engineer’s Manual and follow the instructions.
(Descriptions of setting in this list are the standard values at the time of delivery of DDL-9000A.)
However, contents of function setting are subject to change for improvement of function and performance without notice.
Items with mark are displayed when the machine heads of LH-4168, LH-4168D and LH-4188 are selected.
