5-6. Replacement of conveyor motor
Detach the C cover B6S and replace the motor.
Using the screw (A), remove the motor together with the bracket, and use the screw (B) to
remove the motor .
Be careful not to damage the gear head when removing the motor.
Do assembly so that the dimensions around the pulley (C) are as specified in the figure below.
Transfer motor (part No.: 40045718)
