Julabo CORIO CD-900F - Closed Stainless Steel Bath Tanks

Preparations for operating the device
19
8.2 Closed stainless steel bath tanks
Intended use
JULABO BC4, BC6, BC12 and BC26 closed stainless steel baths can
be combined with JULABO circulators from the CORIO product
series. When combined with these circulators they are designed for
controlling the temperature of JULABO recommend liquid media.
Technical details for the sealed baths
The circulators feature the bracket which is secured to the
baths.
Type
BC4
BC6
BC12
BC26
Order No.
9905504
9905506
9905512
9905526
Temperature range
°C
+20…+300
Approx. weight
kg
5.2
6.4
8.2
15.0
Dimensions (WxDxH*)
cm
23x41x42
24x44x47
33x49x47
39x62x48
Useful bath opening
(WxLxD), inner
cm
13x15x15
13x15x20
22x15x20
26x35x20
Filling volume
Min. … Max.
l
3.0…4.5
4.5…6.0
8.5 … 12.0
19.0 …26.0
Materials for parts in
contact with the
medium
Bath and drain cock: 1.4301 / 304H
Bath/Bath cover seal: FKM Viton®
O-ring on drain cock: FKM Viton®
* / With circulator
