Julabo CORIO CD-900F - Technical Data; Circulator Specifications

Technical data
46
13 Technical data
13.1 Technical data for circulator
Circulator
CORIO

CP
Working temperature range
°C
20 ... 200
Temperature stability
°C
±0.02
Temperature setting
Digital
Temperature display
LED
Resolution
°C
0.01…0.1
ATC - Absolute Temperature Calibration
3-point
Temperature control
PID1
Heating capacity (at 100 V)
kW
0.8
Heating capacity (at 115 V)
kW
1.0
Heating capacity (at 230 V)
kW
1.5 - 2.0
Circulating pump:
Delivery rate at 0 bar
L/min
8…27
Pressure at 0 liters
bar
0,1…0,7
Max. viscosity
cSt
50
Dimensions (WxDxH) without bracket
cm
13.2 x 16.0 x 35,5
Useful immersion depth
cm
16
Weight
kg
2.5
Ambient temperature range
°C
5 ... 40
Mains power connection
V / Hz
100-115
±
10 % / 50 / 60
Power consumption (at 100 V)
A
9-10
Mains power connection
V / Hz
200-230
±
10 % / 50 / 60
Power consumption (230 V)
A
9-10
For CH and GB model (at 230 V)
A
9-10
Classification to DIN 12876-1
III (FL)
