Materials of parts in contact with the bath fluid
53
• All such work must be documented. The operator must keep
records and archive them for at least five years. The records
must be submitted to the relevant authority on request.
Refer to the text of the Regulation for further information.
14 Materials of parts in contact with the bath fluid
14.1 Circulator
Description Material
Motor 1.4301
Pump PPS
Heater 1.4404 / 316L
Sensor 2xPt 100 metal, fitted 1.4571
Sensor connection 1.4301
Float 1.4401
Float pipe 1.4571
Clamp 1.4301
Tubing FPM / FKM
15 Accessories
A wide selection of accessories is available for the following
products at www.julabo.com
for optimum adaption to your
temperature control task.
15.1 For external connection
• Bath fluids
• Tubing
• Shut-off valve
• Barbed fittings
• Adapters
