5 Configuration and parameter tables
Logic output 1 (open-collector output 1)
C221 Function of the logic output 1
X
0 no function
1lk7
2lk8
3fault output
You will find additional information in
“Setting the limit values (limit comparators)” on page 16 and
“Fault output” on page 17
C222 Signal of logic output 1 on
probe break/short-circuit
X
0 active
1inactive
2unchanged
Para-
meter
Explanation Value range factory
setting
X
C223 Lower switching
differential (hysteresis)
0—250
100
The value range corresponds to 0 — 2.5%.
Para-
meter
Explanation Value range factory
setting
X
C224 Upper switching
differential (hysteresis)
0—250
100
The value range corresponds to 0 — 2.5%.
