JUMO dTRANS T02 LCD - Page 67

29
5 Configuration and parameter tables
Logic output 2 (open-collector output 2)
C231 Function of the logic output 2
X
0 no function
1lk7
2lk8
3Frequency output
You will find additional information in
“Setting the limit values (limit comparators)” on page 16 and
“Frequency output” on page 18
C232 Signal of the logic output 2 on
probe break/short-circuit
X
0 active or frequency C236
1inactive or frequency C235
2unchanged
Para-
meter
Explanation Value range factory
settting
X
C233 Lower switching
differential (hysteresis)
0—250
100
The value range corresponds to 0 — 2.5%.
Para-
meter
Explanation Value range factory
setting
X
C234 Upper switching
differential (hysteresis)
0—250
100
The value range corresponds to 0 — 2.5%.
Para-
meter
Explanation Value range factory
setting
X
C235 Frequency at
range start
10 —
1000Hz
10
