Jungheinrich EJC 112 User Manual

B 3
1004.GB
3 Standard Version Specifications
Z
Technical specification details in accordance with VDI 2198. Technical modifications
and additions reserved.
3.1 Performance data for standard trucks
3.2 Dimensions
1) for ZT mast: at 100 mm free lift (h2) u h1+ 50 mm
2) telescopic mast only (ZT)
3) ZZ mast only
Description EJC 110 EJC 112
Q Rated capacity 1000 1200 kg
C Load centre distance
Standard fork length
600 600 mm
Travel speed
w. nominal load / w.o. load
6.0 / 6.0 6.0 / 6.0 km/h
Raise lift speed
w. nominal load / w.o. load
13 / 24 12 / 21 cm/s
Lowering speed
w. nominal load / w.o. load
40 / 42 40 / 42 cm/s
Max. gradeability (5 min rating)
w / w.o. load
816 %
Description EJC 110 EJC 112
h1 Height (mast-dependent) 1) 1750 - 2100 1700 - 2250 mm
h2 Free lift 2) 100 100 mm
h2 Free lift (duplex) 3)
(mast-dependent)
- 1227 - 1777 mm
h3 Lift (mast-dependent) 2500 - 3200 2500 - 3600 mm
h4 Mast height extended
(mast-dependent)
2973 - 3673 2973 - 4073 mm
h13 Load fork lowered 90 90 mm
h14 Tiller height in
min. / max setting
820/1310 820/1310 mm
y Wheelbase 1171 1171 mm
l1 Overall length 1787 1787 mm
l2 Length incl. fork back 637 637 mm
B Truck width 800 800 mm
b5 Distance between forks, outer 560 560 mm
m2 Ground clearance 30 30 mm
Ast Working aisle width
800 x 1200 longit.
2096 2096 mm
Ast Working aisle width
800 x 1200 longit. (in
accordance with VDI)
2234 2234 mm
Wa Turning radius in shunt mode
(tiller vertical)
1383 1383 mm
B 3
1004.GB
3 Standard Version Specifications
Z
Technical specification details in accordance with VDI 2198. Technical modifications
and additions reserved.
3.1 Performance data for standard trucks
3.2 Dimensions
1) for ZT mast: at 100 mm free lift (h2) u h1+ 50 mm
2) telescopic mast only (ZT)
3) ZZ mast only
Description EJC 110 EJC 112
Q Rated capacity 1000 1200 kg
C Load centre distance
Standard fork length
600 600 mm
Travel speed
w. nominal load / w.o. load
6.0 / 6.0 6.0 / 6.0 km/h
Raise lift speed
w. nominal load / w.o. load
13 / 24 12 / 21 cm/s
Lowering speed
w. nominal load / w.o. load
40 / 42 40 / 42 cm/s
Max. gradeability (5 min rating)
w / w.o. load
816 %
Description EJC 110 EJC 112
h1 Height (mast-dependent) 1) 1750 - 2100 1700 - 2250 mm
h2 Free lift 2) 100 100 mm
h2 Free lift (duplex) 3)
(mast-dependent)
- 1227 - 1777 mm
h3 Lift (mast-dependent) 2500 - 3200 2500 - 3600 mm
h4 Mast height extended
(mast-dependent)
2973 - 3673 2973 - 4073 mm
h13 Load fork lowered 90 90 mm
h14 Tiller height in
min. / max setting
820/1310 820/1310 mm
y Wheelbase 1171 1171 mm
l1 Overall length 1787 1787 mm
l2 Length incl. fork back 637 637 mm
B Truck width 800 800 mm
b5 Distance between forks, outer 560 560 mm
m2 Ground clearance 30 30 mm
Ast Working aisle width
800 x 1200 longit.
2096 2096 mm
Ast Working aisle width
800 x 1200 longit. (in
accordance with VDI)
2234 2234 mm
Wa Turning radius in shunt mode
(tiller vertical)
1383 1383 mm
