Jungheinrich EJC 112 - Checking Electrical Fuses

F 11
0307.GB
6.8 Checking electrical fuses
– Prepare the truck for maintenance and repairs (see Section 6.1).
– Remove the front panel (see Section 6.2).
– Check the fuse rating and condition in accordance with the table; replace if
necessary.
Item To protect: EJC 110/112
9 Overall control fuse F1 10 A
10 Hourmeter control fuse 6F2 2 A
11 Travel/Lift fuse F15 200 A
9
10
11
