Jungheinrich EJC 112 User Manual

F 9
0307.GB
6.4 Checking the hydraulic oil level
– Prepare the truck for maintenance and repairs (see Chapter 6.1).
– Remove the front panel (see section 6.2).
– Check hydraulic oil level in hydraulic reservoir.
M
There are markings on the hydraulic reservoir. The oil level must be checked when
the load forks are lowered.
– If necessary add hydraulic oil of the
correct grade (see Section 5) – see
table.
M
Installation is the reverse order.
6.5 Check transmission oil level
– Prepare the truck for maintenance and repairs (see Chapter 6.1).
– Remove the front panel (see section 6.2).
– Turn the tiller to the right stop.
– Check the transmission oil level – it should be at the control plug level (see
Section 5).
– If necessary add transmission oil of the correct grade (see Section 5).
M
Installation is the reverse order.
Tank Marking
Marking 1 2
110 ZT up to 320
112 ZT up to 360
112 ZZ up to 360
F 9
0307.GB
6.4 Checking the hydraulic oil level
– Prepare the truck for maintenance and repairs (see Chapter 6.1).
– Remove the front panel (see section 6.2).
– Check hydraulic oil level in hydraulic reservoir.
M
There are markings on the hydraulic reservoir. The oil level must be checked when
the load forks are lowered.
– If necessary add hydraulic oil of the
correct grade (see Section 5) – see
table.
M
Installation is the reverse order.
6.5 Check transmission oil level
– Prepare the truck for maintenance and repairs (see Chapter 6.1).
– Remove the front panel (see section 6.2).
– Turn the tiller to the right stop.
– Check the transmission oil level – it should be at the control plug level (see
Section 5).
– If necessary add transmission oil of the correct grade (see Section 5).
M
Installation is the reverse order.
Tank Marking
Marking 1 2
110 ZT up to 320
112 ZT up to 360
112 ZZ up to 360
