2 Controls and Displays
Item Control /
Display
EJC 110 EJC 112 Function
1 Battery connector
(Emergency Stop)
ttThe circuit is interrupted, all
electrical functions are cut out. The
truck automatically brakes.
2 Switch switch ttSwitches control current on and off.
Removing the key prevents the
truck from being switched on by
unauthorised personnel.
3Keypad
(CANCODE)
ooSwitches control current on and off.
Code settings.
Releasing and selecting the travel
programs.
Entering travel parameters.
ISM access module ooCode settings.
Releasing and selecting the travel
programs.
Entering travel parameters.
4 Battery discharge
indicator
ttBattery charge status.
Display instrument
(CANDIS)
ooOperating hours meter.
Battery charge status.
Displays service messages and
travel parameters in combination
with CANCODE.
5 Tiller ttIs used to steer the truck.
6 “Shunt” switch ttIf the tiller is in the upper braking
zone, braking can be overriden by
pressing the switch, and the truck
can move with reduced speed
(shunting).
7 Controller ttControls travel direction and speed.
t = Standard equipment o = Optional Equipment
0606.GB
E 2
2 Controls and Displays
Item Control /
Display
EJC 110 EJC 112 Function
1 Battery connector
(Emergency Stop)
ttThe circuit is interrupted, all
electrical functions are cut out. The
truck automatically brakes.
2 Switch switch ttSwitches control current on and off.
Removing the key prevents the
truck from being switched on by
unauthorised personnel.
3Keypad
(CANCODE)
ooSwitches control current on and off.
Code settings.
Releasing and selecting the travel
programs.
Entering travel parameters.
ISM access module ooCode settings.
Releasing and selecting the travel
programs.
Entering travel parameters.
4 Battery discharge
indicator
ttBattery charge status.
Display instrument
(CANDIS)
ooOperating hours meter.
Battery charge status.
Displays service messages and
travel parameters in combination
with CANCODE.
5 Tiller ttIs used to steer the truck.
6 “Shunt” switch ttIf the tiller is in the upper braking
zone, braking can be overriden by
pressing the switch, and the truck
can move with reduced speed
(shunting).
7 Controller ttControls travel direction and speed.
t = Standard equipment o = Optional Equipment
