Juniper E Series User Manual

CT1 and CE1 I/O Modules ! 169
Appendix A: Cable Pinouts
10 Port 4 TX TIP 35 Port 4 TX RING
11 Port 5 RX TIP 36 Port 5 RX RING
12 Port 5 TX TIP 37 Port 5 TX RING
13 Port 6 RX TIP 38 Port 6 RX RING
14 Port 6 TX TIP 39 Port 6 TX RING
15 Port 7 RX TIP 40 Port 7 RX RING
16 Port 7 TX TIP 41 Port 7 TX RING
17 Port 8 RX TIP 42 Port 8 RX RING
18 Port 8 TX TIP 43 Port 8 TX RING
19 Port 9 RX TIP 44 Port 9 RX RING
20 Port 9 TX TIP 45 Port 9 TX RING
21 no connect 46 no connect
22 no connect 47 no connect
23 no connect 48 no connect
24 no connect 49 no connect
25 no connect 50 no connect
Table 41: Pinout of 50-pin Telco connector to ports 10–19
Pin Signal Pin Signal
1 Port 10 RX TIP 26 Port 10 RX RING
2 Port 10 TX TIP 27 Port 10 TX RING
3 Port 11 RX TIP 28 Port 11 RX RING
4 Port 11 TX TIP 29 Port 11 TX RING
5 Port 12 RX TIP 30 Port 12 RX RING
6 Port 12 TX TIP 31 Port 12 TX RING
7 Port 13 RX TIP 32 Port 13 RX RING
8 Port 13 TX TIP 33 Port 13 TX RING
9 Port 14 RX TIP 34 Port 14 RX RING
10 Port 14 TX TIP 35 Port 14 TX RING
11 Port 15 RX TIP 36 Port 15 RX RING
12 Port 15 TX TIP 37 Port 15 TX RING
13 Port 16 RX TIP 38 Port 16 RX RING
14 Port 16 TX TIP 39 Port 16 TX RING
15 Port 17 RX TIP 40 Port 17 RX RING
16 Port 17 TX TIP 41 Port 17 TX RING
17 Port 18 RX TIP 42 Port 18 RX RING
18 Port 18 TX TIP 43 Port 18 TX RING
19 Port 19 RX TIP 44 Port 19 RX RING
Table 40: Pinout of 50-pin Telco connector to ports 0–9 (continued)
Pin Signal Pin Signal
