NOTE: The front side of a switch is the side where the ports are located. The rear side is where
the fans are located.
Figure 51: Back-to-Front Airow Through the EX4100-48T-AFI Switch
Mixing components with dierent airow direcons in the same chassis hampers the performance of
the cooling system of the switch and leads to overheang of the chassis.
