Page #107 background image
Table 24: Virtual Chassis Ports (VCPs) Connector Pinout Information (continued)
Pin NamePin Number
P2TXP2A29
P2TXN2A30
GNDA31
P2TXP3A32
P2TXN3A33
GNDA34
GNDB1
P1RXP0B2
P1RXN0B3
GNDB4
P1RXP1B5
P1RXN1B6
GNDB7
P1RXP2B8
P1RXN2B9
GNDB10
P1RXP3B11
P1RXN3B12
GNDB13
NCB14
NCB15
NCB16
NCB17
NCB18
83Copyright © 2010, Juniper Networks, Inc.
