Table 24: Virtual Chassis Ports (VCPs) Connector Pinout Information (continued)
Pin NamePin Number
NCB19
NCB20
NCB21
GNDB22
P2RXP0B23
P2RXN0B24
GNDB25
P2RXP1B26
P2RXN1B27
GNDB28
P2RXP2B29
P2RXN2B30
GNDB31
P2RXP3B32
P2RXN3B33
GNDB34
Related Topics Virtual Chassis Cabling Configuration Examples for EX4200 Switches on page 107
Planning the Virtual Chassis on page 106
Understanding Virtual Chassis Components
Understanding Virtual Chassis Hardware Configuration on an EX4200 Switch on
page 105
Connecting a Virtual Chassis Cable to an EX4200 Switch on page 139
Copyright © 2010, Juniper Networks, Inc.84
Complete Hardware Guide for EX3200 and EX4200 Ethernet Switches

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Juniper EX4200 Series and is the answer not in the manual?

Juniper EX4200 Series Specifications

General IconGeneral
Switching Capacity128 Gbps
Ports24 or 48 10/100/1000BASE-T ports
Virtual ChassisUp to 10 switches
Layer 3 RoutingYes
Maximum VLANs4096
DRAM1 GB
Flash Memory1 GB
Humidity5% to 90% non-condensing
Power SupplyAC or DC options
MAC Address Table Size32, 000 entries
Operating Temperature0°C to 45°C
Layer 2 FeaturesVLAN, STP, RSTP, MSTP, LACP
ManagementCLI, Web UI, SNMP
Storage Temperature-40°C to 70°C
Input VoltageAC: 100-240V; DC: -48V
