ONLINE Button–The ONLINE button on the port module front panel toggles the port
module online and offline
Controls
Either slot in SRX5K-FPC-IOC Flex IOCSupported Slots
Approximately 1.6 lb (0.7 kg)Weight
OK/FAIL LED, one bicolor:
•
Steady green–The port module is operating normally.
•
Red–The port module has failed and is not operating normally.
•
Off–The port module is powered down.
LINK LED, single color, one per port:
•
Steady green–The link is active.
•
Off–No link.
LEDs
The serial number label is located as shown in Figure 18 on page 35.
Figure 18: Port Module SRX-IOC-4XGE-XFP Serial Number Label
g030303
JX0123
Serial number
ID label
Serial Number Location
35
