Slot for Routing EngineCables and connectors
NoneControls
•
SRX5400–Only bottom slots 0 and 1/0
•
SRX5600–Only bottom slots 0 and 1
•
SRX5800–Only center slots 0, 1, and 2/6
Supported Slots
150 WPower Requirement
Approximately 10 lb (4.5 kg)Weight
OK/FAIL LED, one bicolor:
•
Green–The SCB is operating normally.
•
Red–The SCB has failed and is not operating normally.
•
Off–The SCB is powered down.
FABRIC ONLY LED:
•
Green–The SCB is operating in fabric-only mode.
•
Off–The SCB is operating in fabric/control board mode.
FABRIC ACTIVE LED:
•
Green–The fabric is in active mode.
LEDs
