SSG 140 Series Hardware Installation and Configuration Guide
12 Front Panel
Port Descriptions
This section explains the purpose and function of the following:
Ethernet Ports
Console Port
AUX Port
Ethernet Ports
Eight 10/100 Fast Ethernet ports provide LAN connections to hubs, switches, local
servers, and workstations. You can also designate an Ethernet port for management
traffic. The ports are labeled 0/0 through 0/7. For the default zone bindings for each
Ethernet port, see “Default Device Settings” on page 30.
The SSG 140 device also has two 10/100/1000 Gigabit Ethernet ports (copper) to
provide connectivity to Gigabit Ethernet LANs. The Gigabit ports are labeled 0/8 and
0/9.
When configuring one of the ports, reference the interface name that corresponds
to the location of the port. From left to right on the front panel, the interface names
for the ports are ethernet0/0 through ethernet0/9.
Figure 4 displays the location of the LEDs on each Ethernet port.
ALARM Red On steadily Critical alarm:
Failure of hardware component or software module.
Firewall attacks detected.
Amber On steadily Major alarm:
Low memory (less than 10% remaining).
High CPU utilization (more than 90% in use).
Session full.
Maximum number of VPN tunnels reached.
HA status changed or redundant group member not
found.
Off No alarms.
HA (High
Availability)
Green On steadily Unit is the primary (master) device.
Amber On steadily Unit is the secondary (backup) device.
Off High availability not enabled.
PIM (1-4) Green On steadily PIM is ready for activity.
Blinking Traffic is present.
Off PIM is not present or is installed incorrectly.
Name Color Status Description
