Default Device Settings 31
Table 7: Default Port and Zone Bindings for an SSG 140 Device
Note that the ethernet0/0 interface has the default IP address 192.168.1.1/24 and is
configured for management services. If you connect the 0/0 port on the SSG 140
device to a workstation, you can configure the device from a workstation in the
192.168.1.1/24 subnetwork using a management service such as Telnet. You can
change the default IP address on the ethernet0/0 interface to match the addresses
on your LAN.
Port Label Interface Zone
10/100 Ethernet ports:
0/0 (default IP address is 192.168.1.1/24) ethernet0/0 Trust
0/1 ethernet0/1 DMZ
0/2 ethernet0/2 Untrust
0/3 ethernet0/3 Null
0/4 ethernet0/4 Null
0/5 ethernet0/5 Null
0/6 ethernet0/6 Null
0/7 ethernet0/7 Null
10/100/1000 Gigabit Ethernet ports:
0/8 ethernet0/8 Null
0/9 ethernet0/9 Null
WAN PIM ports: (x = PIM slot, 1 through 4)
ISDN bri(x/0) Untrust
T1 serial(x/0) Untrust
E1 serial(x/0) Untrust
Serial serial(x/0) Untrust
