JVC GY-HM70E User Manual

Camera
Item Details
Power supply Using AC adapter: DC 11 V
Using battery pack: DC 7.2 V
Power consumption 3.6 W (50i mode, MONITOR BRIGHTNESS: 3
(standard))
3.8 W (50i mode, MONITOR BRIGHTNESS: 4
(brighter))
4.0 W (50p mode, MONITOR BRIGHTNESS: 3
(standard))
4.2 W (50p mode, MONITOR BRIGHTNESS: 4
(brighter))
Rated Current Consumption: 1A
Dimensions (mm) 227 x 232 x 472
(W x H x D: excluding grip belt)
Mass Approx. 2.9 kg (camera only),
Approx.
3.1
kg (with two BN-VF823U battery packs
attached)
Operating
environment
Allowable operating temperature: 0°C to 40°C
Allowable storage temperature: -20°C to 50°C
Allowable relative humidity: 35 % to 80 %
Image pickup
device
1/2.3" 12,760,000 pixels (CMOS, back-
illuminated)
Recording area
(Video)
2,070,000 to 5,400,000 pixels (image stabilizer:
OFF, dynamic zoom: ON)
Recording area
(Still image)
4,500,000 to 6,040,000 pixels (4:3) (image
stabilizer: OFF)
2,070,000 to 5,400,000 pixels (16:9) (image
stabilizer: OFF)
Lens F1.2 - F2.8, f = 3.76 mm to 37.6 mm
Video
35 mm conversion: 29.5 mm to 476 mm (dynamic
zoom: ON)*
35 mm conversion: 29.5 mm to 406 mm (dynamic
zoom: OFF)*
Still Image
35 mm conversion: 29.8 m to 345 mm (4:3)
35 mm conversion: 34.4 m to 397 mm (16:9)
* Calculated when “IS” is set to “OFF” on the wide
(W)
end
and “IS” is set to “ON (AIS)” on the tele (T)
end.
Item Details
Filter diameter 46 mm (screw pitch: 0.75 mm)
Lowest illumination 10 lux (GAIN UP: ON)
1 lux (GAIN UP: AUTO SLOW-SHUTTER)
1 lux (SCENE SELECT: NIGHTALIVE)
Zoom (during video
recording)
Optical zoom: Up to 10x
Dynamic zoom: 11 - 16x (image stabilizer: OFF),
11 - 14x (image stabilizer: ON), 11- 13x (image
stabilizer: ON (AIS))
Digital zoom: Up to 200x
Zoom (during still
image recording)
Optical zoom: Up to 10x
Continuous
shooting speed
(during video
record-standby)
LOW SPEED: Approx. 1.5 images/second
(Maximum)
CONT. SHOOTING
SPEED
(during still image
recording)
HIGH SPEED: Approx. 12.5 images/second
MEDIUM SPEED: Approx. 6.25 images/second
LOW SPEED: Approx. 2 images/second
(Maximum)
LCD monitor 3.0", 230,000 pixels, color LCD
Viewfinder 0.24", 260,000 pixels, color LCD
Recording Media SD/SDHC/SDXC card (commercially available)
“Types of Usable SD Card” (A p. 7)
Clock battery Primary battery
Specifications
133

JVC GY-HM70E Specifications

General

Sensor type	CMOS
Total megapixels	12 MP
Optical sensor size	1/2.3 \
Filter size	46 mm
Optical zoom	10 x
Image stabilizer	Yes
Focal length range	3.76 - 37.6 mm
Interchangeable lens	-
Maximum aperture number	2.8
Minimum aperture number	1.2
Focal length (35mm film equivalent)	29.5 - 476 mm
Memory slots	2
Camcorder media type	Memory card
Disc types supported	No
Compatible memory cards	SD, SDHC, SDXC
Internal storage capacity	- GB
Focus adjustment	Auto/Manual
Camera shutter speed	0.00025 - 0.5 s
Display diagonal	3 \
Display aspect ratio	16:9
Display resolution (numeric)	230000 pixels
Viewfinder screen size	0.24 \
Camcorder type	Shoulder camcorder
Product color	Black
Video resolutions	720 x 576, 1920 x 1080 pixels
Video formats supported	AVCHD, H.264, MPEG4
Maximum video resolution	1920 x 1080 pixels
Image formats supported	JPG
Maximum image resolution	- pixels
Headphone outputs	1
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) out	0
Battery voltage	7.2 V
Battery capacity	- mAh
Battery life (max)	- h
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	35 - 80 %
Cables included	RCA, USB

Weight and Dimensions

Depth	476 mm
Width	227 mm
Height	232 mm
Weight	3000 g
