Playing Back Still Images
You can
select and play back the recorded still images from an index screen
(thumbnail display).
1
Check that the unit is in the still image mode.
.
0
Check if still image mode B is activated.
0
If video mode (
A) is activated, switch to still image mode (B).
“Selecting Video/Still Image Recording Mode” (A p. 19)
2
Tap <<MEDIA to select the playback mode.
.
MENU
MENU
MEDIA
3
Tap on the file to start playback.
.
0
Tap s/t to
select the media for playback and change the index
screen (thumbnail display).
0
Tap u to return to the index screen.
0
L appears on the last image played back.
0
Lines in different colors are displayed to distinguish the recording
date.
Operation Buttons for Still Image Playback
During Index Screen Display
.
CAM
5
1 2
6 7 8 9
3
0
4
Display Description
A
Video/Still Image
Mode
Switches between video (50i/50p) and still
image modes.
B
Date Moves to the previous/next date
C
> Displays the next index screen (thumbnail
display)
0
You
can
perform the same operation with the
zoom lever.
D
< Displays the previous index screen (thumbnail
display)
0
You can
perform the same operation with the
zoom lever.
E
<<CAM Switches to the camera (recording) mode.
F
W
Still images that are recorded continuously
within 2 seconds or with the continuous
shooting mode will be grouped together and
displayed with a green frame on a separate
index screen.
The
index
screen changes between the normal
index screen and group index screen with
every tap of the button.
G
A
Displays the index screen (thumbnail display)
to perform deletion
H
s/t Switches between the SD card slots.
I
MENU Displays the menu screen
J
File (Still Image) Tap on thumbnail - Starts playback
Drag to right - Scrolls to the right to show the
previous index screen (thumbnail display)
Drag
to
left - Scrolls to the left to show the next
index screen (thumbnail display)
Playback
52
