JVC GY-HM70E User Manual

Installing the Provided Software
You can display the recorded images in calendar format and perform simple
editing using the provided software.
1
Load the provided CD-ROM into your computer.
Windows Vista / Windows 7
A Click “Run INSTALL.EXE” in the auto play dialog box.
B Click “Continue” on the user account control screen.
0
If the screen does not appear, open CD-ROM in “Computer” (or “My
Computer”) and double-click “install” (or “install.exe”).
Windows XP
0
Go to Step 2.
2
Click “Everio MediaBrowser 4”.
.
0
Follow the on-screen instructions.
3
Click “Finish”.
.
0
Installation ends and icons are created on the desktop.
Backing Up All Files
Before making backup, make sure that enough free space is left in the
computer's hard disk (HDD).
Backup will not start if there is not enough free space.
1
Remove the AC adapter and battery pack from this unit.
2
Connect the USB cable and the AC adapter.
.
1
2
Computer
To USB Connector
To DC Connector
AC Adapter To
AC Outlet
USB Cable (Provided)
A Connect using the provided USB cable.
B Connect the AC adapter to this unit.
3
Set the “STANDBY/ON OFF” switch to “ON”.
.
0
When this unit is turned on, the “SELECT DEVICE” screen appears.
4
Tap “CONNECT TO PC”.
.
CONNECT TO PC
TYPE TO CONNECT
SELECT DEVICE
SELECT DEVICE
Copying
96

JVC GY-HM70E Specifications

General

Sensor type	CMOS
Total megapixels	12 MP
Optical sensor size	1/2.3 \
Filter size	46 mm
Optical zoom	10 x
Image stabilizer	Yes
Focal length range	3.76 - 37.6 mm
Interchangeable lens	-
Maximum aperture number	2.8
Minimum aperture number	1.2
Focal length (35mm film equivalent)	29.5 - 476 mm
Memory slots	2
Camcorder media type	Memory card
Disc types supported	No
Compatible memory cards	SD, SDHC, SDXC
Internal storage capacity	- GB
Focus adjustment	Auto/Manual
Camera shutter speed	0.00025 - 0.5 s
Display diagonal	3 \
Display aspect ratio	16:9
Display resolution (numeric)	230000 pixels
Viewfinder screen size	0.24 \
Camcorder type	Shoulder camcorder
Product color	Black
Video resolutions	720 x 576, 1920 x 1080 pixels
Video formats supported	AVCHD, H.264, MPEG4
Maximum video resolution	1920 x 1080 pixels
Image formats supported	JPG
Maximum image resolution	- pixels
Headphone outputs	1
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) out	0
Battery voltage	7.2 V
Battery capacity	- mAh
Battery life (max)	- h
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	35 - 80 %
Cables included	RCA, USB

Weight and Dimensions

Depth	476 mm
Width	227 mm
Height	232 mm
Weight	3000 g
