JVC GY-HM70E User Manual

Creating Discs with a BD Writer (External
Blu-ray Drive)
*The JVC external Blu-ray drive is known as “BD writer”.
You can
copy the recorded files to discs or play back the created discs using
an optional BD writer (external Blu-ray drive).
Compatible BD Writers (External Blu-ray Drives)
You can use BE12LU30 from LG. (as of January, 2013)
Creating Discs with a BD Writer (External Blu-ray Drive)
o
Preparing a BD Writer (External Blu-ray Drive)
“Preparing a BD Writer (External Blu-ray Drive)” (A p. 69)
o
Copying to Discs
“Copying All Files” (A
p. 70)
“Copying Files by Date” (A p. 72)
“Copying Selected Playlists” (A p. 73)
“Copying Selected Files” (A p. 75)
Select and copy the desired videos or still images individually.
o
Other Operations
“Playing Back with a BD Writer (External Blu-ray Drive)” (A p. 77)
Memo :
0
Discs in the DVD-Video format cannot be created.
0
50i videos, 50p videos and still images cannot be saved together on a
disc.
0
The recordable time on the disc varies according to the way of recording.
0
When there are many files to back up, it may take time for the backup to
be completed. Wait for a while as the access lamp appears blinking, which
indicates normal operation.
0
Date and time information as saved as subtitles in the created discs.
Preparing a BD Writer (External Blu-ray Drive)
Memo :
0
When connecting
this unit to the BD writer (external Blu ray drive), use an
Mini-A (male) - B (male) USB conversion cable. Please note that the
supplied USB cable cannot be used for this purpose.
0
To use the USB cable provided with the BD writer (external Blu-ray drive),
purchase the following USB conversion cable.
Part number: QAM0852-001 * Mini-A (Male) – A (Female)
*Consult your nearest service center.
1
Remove the AC adapter and battery pack from this unit.
2
Connect the USB cable and the AC adapter.
.
1
3
2
4
AC Adapter To
AC Outlet
To DC
Connector
To USB Connector
BD Writer
A Connect the
USB cable of the BD writer (external Blu-ray drive) to this
unit.
0
The USB cable provided with this unit cannot be used.
B Connect the AC adapter of the BD writer (external Blu-ray drive).
C Turn on the BD writer (external Blu-ray drive).
D Connect the AC adapter to this unit.
0
Refer also to the instruction manual of the BD writer (external Blu-ray
drive).
Copying
69

JVC GY-HM70E Specifications

General

Sensor type	CMOS
Total megapixels	12 MP
Optical sensor size	1/2.3 \
Filter size	46 mm
Optical zoom	10 x
Image stabilizer	Yes
Focal length range	3.76 - 37.6 mm
Interchangeable lens	-
Maximum aperture number	2.8
Minimum aperture number	1.2
Focal length (35mm film equivalent)	29.5 - 476 mm
Memory slots	2
Camcorder media type	Memory card
Disc types supported	No
Compatible memory cards	SD, SDHC, SDXC
Internal storage capacity	- GB
Focus adjustment	Auto/Manual
Camera shutter speed	0.00025 - 0.5 s
Display diagonal	3 \
Display aspect ratio	16:9
Display resolution (numeric)	230000 pixels
Viewfinder screen size	0.24 \
Camcorder type	Shoulder camcorder
Product color	Black
Video resolutions	720 x 576, 1920 x 1080 pixels
Video formats supported	AVCHD, H.264, MPEG4
Maximum video resolution	1920 x 1080 pixels
Image formats supported	JPG
Maximum image resolution	- pixels
Headphone outputs	1
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) out	0
Battery voltage	7.2 V
Battery capacity	- mAh
Battery life (max)	- h
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	35 - 80 %
Cables included	RCA, USB

Weight and Dimensions

Depth	476 mm
Width	227 mm
Height	232 mm
Weight	3000 g
