MX-J170V
1-14
Disconnect the harness from connector PCON1 of
the VCD board .
Remove the four screws W attaching the Sealed and
VCD board.
1.
2.
Prior to performing the following procedure, remove
the CD changer unit.
Removing the VCD board
(See Fig.31)
<CD changer unit>
Turn the black loading pulley gear marked c on the
under side of the CD changer unit in the direction of
the arrow and draw the CD tray toward the front until
it stops.
Disconnect the card wire from connector SCW5 of
the CD servo board on the upper side of the CD
changer unit.
Push down the two tray stoppers marked i and pull
out the CD tray.
1.
2.
3.
Removing the CD tray (See Fig.32 to 34)
Fig.32
Fig.31
Fig.33
Loading pulley gear marked c
CD tray
CD tray
CD tray
CD servo board
SCW5
Tray stopper marked i
Tray stopper marked i
Fig.34
W
W
PCON1
Shield
VCD board
