Parts list(CD changer mechanism)
Q'ty
Description
Block No. M3MM
1 AH66-80022A
SLIDER-CAM 1
2 AH66-60034A
BELY-LOAD
1
3 AH66-20186A
GEAR
1
4 AH66-20187A
GEAR-LOAD 1
5 AH66-20188A
GEAR-CAM
1
6 AH66-20189A
GEAR-TRAY 1
7 AH66-20190A
GEAR-CONVERT
1
8 AH66-20191A
GEAR-SYNCRO
1
9 AH66-20192A
GEAR-WORM
1
10 AH31-12001A
MOTOR-LOADING
1
11 AH66-20193A
GEAR-ROULETTE
1
12 AH66-90056A
TRAY-ROULBTTE
1
13 AH66-90055A
TRAY-DISC
1
14 AH32-10001E
SENSOR
1
15 AH61-20428A-1
BASE MAIN
1
16 3302-000159
MAGNET FERRITE
1
17 AH66-90057A
TABLE-CHUCK
1
18 AH69-20342B
SHEET-CHUCK
4
19 3405-000101
MICRO SWITCH
1
20 AH31-10021A
DC MORTOR
1
9VDC/130MA,
21 AH66-10008A
PULLEY-MOTOR
1
CMS-CR3
22 AH73-10031A
RUBBER-CD
2
23 AH66-30098A
LEVER-LIFTER
1
24 AH73-10034A
RUBBER-CD(G)
2
GREEN
25 AH63-40157B
SHIELD-TOP
1
