9F : Remote Data
The remote control codes for controlling the wired remote controller via RS-232C is as shown in the following table. The codes apply
to all three HDD, BD and SD deck unless otherwise stated.
Code Items Remarks
01 INPUT SELECT
03 STOP
06 F.F/SPEED+
07 REW/SPEED-
0B POWER ON/OFF
0C PLAY
0D PAUSE/STILL
14 FWD SKIP
15 REV SKIP
17 AUDIO
1A Power Off
1D Power On
21 TEN KEY 1
22 TEN KEY 2
23 TEN KEY 3
24 TEN KEY 4
25 TEN KEY 5
26 TEN KEY 6
27 TEN KEY 7
28 TEN KEY 8
29 TEN KEY 9
2A KEY Z
2B TEN KEY 0
2C KEY #
31 REC MODE (XP/SP/LP/
EP…)
32 BD/DVD DECK
34 DUBBING
37 SET UP
3C OK/ENTER
3E ON SCREEN
44 HDD DECK
48 MEDIA MANAGEMENT
80 CURSOR 0° Moves the arrow in the
index
list to the right. (I)
81 MENU BD/DVD Deck only
82 CURSOR 90° Moves the arrow in the
index list to the up. (J)
84 CURSOR 180° Moves the arrow in the
index list to the left. (H)
86 CURSOR 270° Moves the arrow in the
index list to the down.
(K)
87 OPEN/CLOSE BD/DVD Deck only
8E PROGRESSIVE HDD/BD Deck only
8F TOP MENU DVD Deck only
90 MARK HDD/DVD Deck only
96 CM SKIP
AF REV FRAME
B0 -SLOW D
B1 SHUTTLE-C
B2 SHUTTLE-B
B3 SHUTTLE-A
B4 SHUTTLE-2
B5 SHUTTLE-1
B6 -SLOW B
B7 -SLOW C
B8 +SLOW C
B9 +SLOW B
BA SHUTTLE +1
BB SHUTTLE +2
BC SHUTTLE +A
BD SHUTTLE +B
BE SHUTTLE +C
BF +SLOW D
C0 ANGLE/LIVE CHECK ANGLE (BD/DVD Deck
only)
LIVE CHECK (HDD/BD
Deck only)
C4 SUBTITLE DVD Deck only
CC REC
D3 OPTION
D4 RETURN
D5 COLOR KEY BLUE
D7 COLOR KEY RED
D9 JOG -1/6
DA JOG +1/6
DB JOG +1
DC INSTANT REPLAY
DD EDIT
DE COLOR KEY GREEN
DF COLOR KEY YELLOW
E0 NAVIGATION
E1 L-1 Y/C INPUT SELECT HDD Deck only
E2 L-1 COMPOSITE INPUT
SELECT
HDD Deck only
E3 PLAYBACK SETTING
E4 DELETE
E5 INFORMATION
CORRECT
ED FWD FRAME
F2 MODE LOCK
F3 HDCP AUTO
.
100
