Status Data Sense
For acquiring the remaining time in the current recording mode in hours, minutes and seconds for HDD/BD/SD.
D7
STATUS
SENSE
1st Byte 1st Byte 1st Byte 2nd Byte 3rd Byte 4th Byte 5th Byte
HDD BD SD HDD/BD/SD HDD/BD/SD HDD/BD/SD HDD/BD/SD
bit7 1 (Fixed) 1 (Fixed) 1 (Fixed) Video EE 1 (Fixed) During PLAY During PAUSE
(Set to 1
simultaneously
with “During
PLAY” in STILL
mode. Set to 1
simultaneously
with “During
REC” in record
pause mode.)
bit6 0 (Fixed) 1 (Fixed) 1 (Fixed) Audio EE 0 (Fixed) FF in Progress 0 (Fixed)
bit5 0 (Fixed) 0 (Fixed) 1 (Fixed) 0 (Fixed) 0 (Fixed) REW in
Progress
During Reverse
Shuttle Search
(Excluding
STILL)
bit4 Record
Forbidden
Record
Forbidden
Record
Forbidden
0 (Fixed) 0 (Fixed) During STOP During Forward
Shuttle Search
(Excluding
STILL)
bit3 Disc Not
Inserted
Disc Not
Inserted
Disc Not
Inserted
Deck Error 0 (Fixed) During
STANDBY (Unit
Power Off)
Refer to the
SEARCH
SPEED table.
bit2 Tray Open Tray Open Tray Open 0 (Fixed) During Repeat
Playback
(Including
PAUSE)
Recording in
Progress (Disc)
Refer to the
SEARCH
SPEED table.
bit1 0 (Fixed) 0 (Fixed) 0 (Fixed) 0 (Fixed) Recording
Paused (Disc)
Recording in
Progress (HDD)
Refer to the
SEARCH
SPEED table.
bit0 RS-232C
command error
status. Clear
using
56 (Clear).
RS-232C
command error
status. Clear
using 56 (Clear).
RS-232C
command error
status. Clear
using 56 (Clear).
0 (Fixed) Recording
Paused (HDD)
0 (Fixed) Refer to the
SEARCH
SPEED table.
0
TC Data Sense
1st Byte 2nd Byte 3rd Byte 4th Byte 5th Byte 6th Byte 7th Byte 8th Byte
TC Data Sense Hr (Tens) Hr (Ones) Min (Tens) Min (Ones) Sec (Tens) Sec (Ones) Frame (Tens) Frame
(Ones)
D8 3* 3* 3* 3* 3* 3* 3* 3*
E.g. (01:23:45) 30 31 32 33 34 35 30 30
E.g. : When remaining time for the current recording mode of the selected deck is 1 hr 23 min 45 sec.
Frame is fixed as 0.
