6mm
2 mm
6 mm
Fall Prevention Wire
Note
When mounting the camera to the ceiling, ensure to wear
safety glasses to protect the eye from any falling objects.
Mounting the Camera-Mounting Bracket on Top of the Camera
The camera-mounting bracket is originally mounted at the bottom of the
camera before shipment but it can also be mounted on top of the
camera.
When mounting the bracket on top of the camera, make sure to fasten
the screws securely.
1
Remove the camera-mounting bracket fastening screws (x2).
The camera-mounting bracket is removed from the camera.
2
Mount the camera-mounting bracket on top of the camera.
3
Mount the camera onto a fixer, pan/tilt unit and the like.
.
2
BF LOCK
1
Camera-mounting
bracket fastening
screws
Camera-mounting
bracket
3
POWERIRIS
Connection/Installation
E-25
To Next Page
