JVC TK-C9510E - Connection;Installation; Quick Installation

Quick Installation
.
POWER IRIS
(TK-C9510E)
M3 x 6 mm
POWERIRIS
7mm
2 mm
6 mm
MAX.
B
Mounting the Lens (A page 20)
Connection (A page 21)
Monitor
Connect to
external
device (e.g.
sensor)
To AC 24 V or DC 12 V power supply
Connect to remote
control unit, etc.
A
C
Mounting the Camera (A page 24)
Connection/Installation
E-16
