C [RX TERM OFFlON] RX terminal ON/OFF switch
For setting whether to apply termination at a resistance value of 110 K
between the RX+ and RX- control signal connectors.
OFF : Does not terminate.
ON : Terminates.
(Default setting: ON)
Memo
v
If the system including this camera employs an M.DROP
(Multi DROP, RS-485) system, such as RM-P2580, set only
the camera connected at the other end of the control signal
cable to “ON”, and set all other cameras to “OFF”.
v
If [PROTOCOL1] on the [COMMUNICATION (JCCP)]
screen is set to “P to P”, set this switch to “ON”.
D [IRIS VIDEOlDC] Lens selector switch
For setting according to the lens type when an auto iris lens is used.
VIDEO : For lenses built-in with EE amp.
DC : For lenses not built-in with EE amp.
(Default setting: DC)
Setting/Adjustment
E-27
