JVC VR-616
USB ConnectorLAN Connector
Alarm IN Connector
VGA OUT Connector
Y/C OUT
Connector
MONITOR OUT 1,2
Connector
SPOT OUT Connector
RS-485 Connector
IEEE 1394 Connector
VIDEO IN Connector
AUDIO OUT Connector
AUDIO IN Connector
Alarm OUT Connector
3.2 Basic Connections
