-- 62 --
JVC VR-616
5.3.2.2 Events
● Alarm has occurred according to select events such as Disk Full, Admin PW. Changed
Video Loss, Motion Detect.
● Checks event you want to detect from the Events menu by using Jog and ENTER
button.
● Each event type is indicated by the following.
Disk Full : When HDD is fully recorded.
Admin.PW Changed : When Admin Password has been changed.
Video Loss : No video image. Possible to select channel number or ALL.
Motion : When motion is detected. Possible to select channel number or ALL.
● How to off “Alarm” when alarm has occurred
Auto : Alarm is turned off automatically after setting time.
Manual : As press the Alarm button on the front, alarm is turned off.
Time (Sec) : This is for selecting “Auto”. (Unit : Sec)
5.3.2.3 Alarm Off
5.3.2.4 Alarm Output Number
● Select Alarm Output Number by using channel button.(1~4 buttons)
Alarm Output Number is changed according to pressing button.
● Alarm Output port is Open Collector and could be connected to rear port of
the product. It has 4 outputs. Refer to External Product Connections and
Application for the details.
● For Alarm OUT connector, please refer to P.29
