JYE Tech DSO112A - Page 23

DN112-06v02
JYE Tech - 23 - www.jyetech.com
Return:
Remarks:
Get Parameters
Function: Read the current parameters from DSO112A
Format:
Return:
Offset Field Name Size Value
-1 Sync character 1 0xFE
0 Frame ID 1 0xC0
1 Frame Size 2 50
3 Device type 1 0x30 (for
configuration)
4 VSenMax 1
5 VSenMin 1
6 CplMax 1
7 CplMin 1
8 VPosMax 2
10 VPosMin 2
12 Reserved 8
20 TBMax 1
21 TBMin 1
22 Reserved 4
26 TrigModeMax 1
27 TrigModeMin 1
28 TrigSlopeMax 1
29 TrigSlopeMin 1
30 TrigLvlMax 2
32 TrigLvlMin 2
34 TrigPosMax 1
35 TrigPosMin 1
36 TrigSrcMax 1
37 TrigSrcMin 1
38 Reserved 4
42 RecLenMax 4
46 RecLenMin 4
Offset Field Name Size Value
-1 Sync character 1 0xFE
0 Frame ID 1 0xC0
1 Frame Size 2 4
3 Sub Command 1 0x21
