Remarks:
Offset Field Name Size Value
-1 Sync character 1 0xFE
0 Frame ID 1 0xC0
1 Frame Size 2 34
3 Sub command 1 0x31 (for
parameters)
4 VSen 1
5 Cpl 1
6 VPos 2
8 Reserved 4
12 Timebase 1
13 Reserved 3
16 TrigMode 1
17 TrigSlope 1
18 TrigLvl 2
20 TrigPos 1
21 TrigSrc 1
22 Reserved 1
23 Measurements 1
24 Record Length 4
28 Reserved 2
30 HPos 4
